•Steeringcylinderballjoints(2)(Figure51)
Figure51
1.Topttingonkingpin
•Tierodballjoints(2)(Figure51)
•Kingpinbushings(2)(Figure51).Thetoptting
onthekingpinshouldonlybelubricated
annually(2pumps).
•Liftarmbushings(1percuttingunit)(
Figure52)
Figure52
•Liftcylinderbushings(2percuttingunit)(Figure52)
•Liftarmpivotbushings(1percuttingunit)
(Figure53)
•Cuttingunitcarrierframe(2percuttingunit)
(Figure53)
•Cuttingunitliftarmpivot(1percuttingunit)
(
Figure53)
Figure53
