ProductOverview
g032409
Figure13
1.Tractionandreel-drive
engagementlever
6.Fueltank
2.Operator-presencecontrol7.Grassbasket
3.Handle
8.Cuttingunit
4.Servicebrake
9.Transportwheelaxle
5.Controlpanel
Controls
g032410
Figure14
1.Openspaceforoptional
lights
5.Operator-presencecontrol
2.Parking-brakelatch
6.On/offswitch
3.Servicebrake
7.Throttlecontrol
4.Handle8.Tractionandreel-drive
engagementlever
ThrottleControl
Thethrottlecontrol(Figure14andFigure15)is
locatedontheright,rearsideofthecontrolpanel.
Rotatethethrottletoregulatetheenginespeed.
g027738
Figure15
1.Fullspeed
2.Slowspeed
TractionandReel-Drive
EngagementLever
Thetractionandreel-driveengagementlever(Figure
16)islocatedonthefrontrightsideofthecontrol
panel.Fortransportoperation,theleverhas2
positions:NEUTRALandFORWARD.Pushingthelever
forwardengagesthetractiondrive.
Note:Tomovetheleveryoumustrstengagethe
operator-presencecontrol.
