Toro 04044 - Page 15

g000494
Figure16
1.NEUTRAL3.Tractiondrive-engaged
(transport)
2.Tractiondriveneutraland
reeldriveoff
4.Tractiondriveandreel
driveengaged
Forreeloperation,theleverhas2positions:ENGAGE
andDISENGAGE.Movethetopofthelevertotheleft
thenforwardtoengagethereelandbeginmowing.
Pushthelevertotherighttodisengagethereel
andcontinueforwardmotionorpullbackonitto
disengageboththereelandthetractiondrive.
Note:Ifyoureleasetheoperator-presencecontrol,
theleverreturnstoneutralandthemachinestops.
ServiceBrake
Theservicebrake(Figure17)islocatedontheleft
frontsideofthehandle.Pullingtheleverbackwill
applytheservicebrake.Youmustreleasethebrake
beforeyouengagethetractiondrive.
g016853
Figure17
1.Parking-brakelatch
2.Servicebrake
Parking-BrakeLatch
Theparking-brakelatch(Figure17)isusedwiththe
servicebrake.Withtheservicebrakeengaged,rotate
theparking-brakelatchtowardthebrakehandleand
releasetheservicebrakeontothelatchtoholdthe
servicebrakeinplace.Pullthebrakelevertorelease
it.
On/OffSwitch
Theon/offswitch(Figure14)islocatedontopofthe
controlpanel.MovetheswitchtotheONpositionto
starttheengineandOFFtoshutofftheengine.
Operator-PresenceControl(OPC)
Theoperator-presencecontrol(Figure14)mustbe
engagedbeforeengagingthetractionlever.Releasing
theOPCduringoperationreturnsthemachineto
neutralbutdoesnotshutofftheengine.
15
