10
Setup
Note: Determine the left and right sides of the machine from the normal operating position.
Loose Parts
Note: Use this chart as a checklist to ensure all parts necessary for assembly have been shipped. If any of these parts are
missing, total set–up cannot be completed.
Description
Qty. Use
Handle assembly
Cable tie
1
2
Install the handle on the machine
Secure the control cables to the handle
Wheel Shaft, right hand
Wheel Shaft, left hand
1
1
Use when installing optional transport wheels
Spring 1 Mount kickstand, Model 04060 only
Grass basket 1 Install on the machine
Operator’s Manual
1 Read before operating
Engine Owner’s Manual
1 Read before operating
Part’s Catalog
1 Use for ordering parts
Registration card 1 Fill out and return to Toro
Operator video 1 View before operating
Certificate of Compliance 1
To Next Page
