Toro 08120 - Preparing the Machine for Installation

1
Preparing the Machine
No Parts Required
Procedure
1. Park the machine on a level surface.
2. Shift the transmission lever to the P (P ARK )
position.
3. Shut of f the engine and remove the key .
4. W ait for the engine to cool completely .
g364252
Figure 1
5. Disconnect the negative (-) battery cable from
the battery post.
g365494
Figure 2
1. Negative (-) battery cable
2. Battery post
6. Raise the hood; refer to the machine Operator ’ s
Manual .
7. Drain approximately 2 L (1/2 US gallon) of
engine coolant (or until coolant stops owing out
of the rubber hoses) from the cooling system;
refer to the Operator ’ s Manual .
Note: Retain coolant for reuse after installation
of the kit.
