Toro 08703 Service Manual

ServiceandRepairs
Wheels
RemovingtheFrontWheel
g350145
Figure89
1.Frontfork
9.Wheelandtire
17.Setscrew
2.Locknut(2each)10.Lugnut(2or4each)18.Flangenut(3each)
3.Hydraulictube11.Bearingtab
19.Wheelweightadapter(2each)
4.Tubeclampassembly12.Flangette–standard
20.Stud(2each)
5.Hydraulictube13.Bearing21.Wheelweight
6.Capscrew(2each)
14.Flangette–lube
22.Thrustwasher(2each)
7.Frontwheelmotorassembly
15.Capscrew(3each)23.Locknut(2each)
8.Spindle16.Greasetting
1.Parkthemachineonalevelsurface,loweranyattachments,engagethe
parkingbrake,setthekeyswitchtotheOFFpositionandremovethekey
fromtheswitch.
IMPORTANT
Beforeliftingthemachinewithajack,reviewandfollowJacking
Instructions(page1–6).
2.Supportbutdonotraisethefrontofthemachine.
3.Removethefastenersthatsecurethehydraulictubeclamptothefrontfork.
SandPro
®
3040and5040
Page7–3
Chassis:ServiceandRepairs
20251SLRevA
