Toro 08703 Service Manual

AirCleanerAssembly
g340344
Figure12
1.Cap
6.Aircleanercover11.Hoseclamp
2.Hoseclamp
7.Locknut(2each)
12.Intakehose
3.Aircleanerhousing
8.Vacutatorvalve13.Hoseclamp
4.Mountingbracket
9.Capscrew(2each)
5.Filterelement10.Plug
RemovingtheAirCleanerAssembly
RefertoFigure12forthisprocedure.
1.Parkthemachineonalevelsurface,loweranyattachment,applytheparking
brake,setthekeyswitchtotheOFFpositionandremovethekeyfromthe
switch.
2.Removetheaircleanercomponentsasneeded.
3.RefertothetractionunitOperator’sManualforaircleanerserviceand
maintenanceprocedures.
4.Examinetheaircleanerhousingandcoverforwearanddamagethatcould
causepossibleairleaks.Replacecomponentsifnecessary.
5.Examinetheairintakehoseforwearordamageandreplacethehoses
ifnecessary.
InstallingtheAirCleanerAssembly
RefertoFigure12forthisprocedure.
SandPro
®
3040and5040
Page4–9
Engine:ServiceandRepairs
20251SLRevA
