ProcedureDescription
Qty.
Use
Operator’sManual
1
PartsCatalog
1
Clevispin
1
Washer(0.469x0.922inch)
1
5
Hairpincotter1
Readthedocumentationandstorethe
looseparts.
1
AssemblingtheDragMat
Carrier
Partsneededforthisprocedure:
1Drag-mat-carrierassembly
1Attachment-adapterassembly
1
Shoulderbolt
1
Washer(0.531x1.063inch)
3
Washer(0.469x0.922inch)
1
Locknut(7/16inch)
2
Bolt(3/8x2-1/2inches)
4
Washer(3/8x7/8inch)
2
Spacer
2
Locknut(3/8inch)
2
Shackle
2
Clevispin(3/8x1-1/2inches)
2
Cotterpin
Procedure
1.Securethepivotassemblyontheattachmentadapter
tothedrag-matcarrierwithashoulderbolt,washer
(0.531x1.063inch),washer(0.469x0.922inch)and
locknut(7/16inch)asshowninFigure3.
Figure3
1.Shoulderbolt4.Washer(0.469x0.922
inch)
2.Washer(0.531x1.063
inch)
5.Locknut(7/16inch)
3.Pivotassembly6.Drag-matcarrier
2.Securethetoplinkofeachchaintothebackofthelift
armusingabolt(3/8x2-1/2inches),2washers(3/8
x7/8inch),aspacer,andalocknut(3/8inch);refer
toFigure4.
4
