Figure4

1.Chain4.Washer(3/8x7/8inch)

2.Spacer5.Locknut(3/8inch)

3.Bolt(3/8x2-1/2inches)

3.Threadashacklethroughthebottomlinkofeachchain

ontheliftarm(Figure5).

Figure5

1.Chain3.Clevispin(3/8x1-1/2

inches)

2.Shackle4.Cotterpin

4.Secureeachshackletothedrag-mat-carrierassembly

asillustratedinFigure5usingaclevispin(3/8x1-1/2

inches)andacotterpin.

Note:Forproperoperationoftheattachment,the

chainsmustbeslackwhenthedragmatisinthe

lowered(operating)position.

InstallingaMat

Partsneededforthisprocedure:

Steelmat(notincludedinthiskit,orderseparately)

Coconut-bermat(notincludedinthiskit,order

separately)

11Matretainer

Bolt(3/8x1inch)

Flangenut(3/8inch)

Procedure

1.Lineup1edgeofthematwiththerearedgeofthe

carrier.

Important:Ifyouareinstallingthesteelmat,

positionthematsothatthetabsalongthe

outsideedgefacerearwardwhentheinstallation

iscomplete.Thisorientationpreventsthetabs

frombendingandothersubsequentdamagefrom

occurring.

Figure6

1.Tabsfacingrearward
