SteeringControlValve(Model08745)

g351051

Figure64

1.Steeringcontrolvalve

4.Hydraulictube7.Hydraulichose

2.Capscrew(4each)

5.Hydraulichose8.Hydraulictube

3.Locknut(4each)

6.Hydraulichose

RemovingtheSteeringControlValve

1.Parkthemachineonalevelsurface,loweranyattachments,engagethe

parkingbrake,setthekeyswitchtotheOFFpositionandremovethekey

fromtheswitch.

2.Removethefueltankfromthemachine;refertoRemovingandInstalling

theFuelT ank(page4–12).

3.ReadandadheretotheinformationprovidedinGeneralPrecautionsfor

RemovingandInstallingtheHydraulicSystemComponents(page5–54).

4.Cleanthehydraulictubeends,andttingsonthesteeringcontrolvalveto

preventcontaminantsfromenteringintothehydraulicsystem.

5.Labelandremovethehydraulichosesandtubesfromthettingsonthe

controlvalve.Allowthehydrauliclinestodrainintoasuitablecontainer.

6.Installcleancapsandplugsonthehydraulictubesandttingstoprevent

systemcontamination.

7.Removethesteeringwheelfromthemachine;refertoRemovingand

InstallingtheSteeringWheel(page7–13).

8.Supportthesteeringcontrolvalveandremovethefastenersthatsecurethe

steeringcontrolvalvetothemachine.

InstallingtheSteeringControlValve

1.Slidethesteeringcontrolvalveontothevalvesupportandsecurethe

steeringcontrolvalvetothemachinewiththepreviouslyremovedfasteners.

2.Removethecapsandplugsthenconnectthehydrauliclinestothecontrol

valvettings;refertoInstallingHydraulicHosesandTubes(O-RingFace

SealFitting)(page5–7).

SandPro

3040and5040

Page5–99

HydraulicSystem:ServiceandRepairs

20251SLRevA
