Toro 1800 Power Curve Set-Up/Assembly

1800 POWER CURVE
2 Service Instruction TSN0001a
4. Squeeze the upper tubes together and wiggle the
upper tubes down until the mounting holes in the
upper and lower tubing line up:
Left hand (Fig. 005):
5. Place the mounting plate over the tubes and align
the mounting plate holes with the upper and lower
tubing holes (Fig. 007).
Right hand (Fig. 006):
6. Insert the end of the chute crank rod through the
hole in the shroud (Fig. 008).
Fig. 005 PICT-1437
Fig. 006 PICT-1438
Fig. 008 PICT-1443
Fig. 007 PICT-1441

Toro 1800 Power Curve Specifications

General

Type	Electric Snow Blower
Power Source	Corded Electric
Clearing Width	18 inches
Intake Height	12 inches
Throw Distance	25 feet
Weight	25 lbs (11.3 kg)
