Toro 1800 Power Curve Set-Up/Assembly

1800 POWER CURVE
7Service Instruction TSN0001a
5. Loosely install a lock nut to secure one side of the
deectorchuteassembly(Fig.023).
7. Insert the carriage bolt through the lower chute,
rubberwasheranddeectorchute(Fig.025).
6. Positionarubberwasherbetweenthedeector
chute and the lower chute while maintaining the hole
alignment (Fig. 024).
8. Installthemetalatwasherontothecarriagebolt
(Fig. 026).
Fig. 023 PICT-1479
Fig. 024 PICT-1485a
Fig. 026 PICT-1488
Fig. 025 PICT-1484

Toro 1800 Power Curve Specifications

General

Type	Electric Snow Blower
Power Source	Corded Electric
Clearing Width	18 inches
Intake Height	12 inches
Throw Distance	25 feet
Weight	25 lbs (11.3 kg)
