FillingtheEnginewithOil
NoPartsRequired
Procedure
Important:Yourmowerdoesnotcomewithoil
intheengine.Beforestartingtheengine,llthe
enginewithoil.
Max.ll:20oz.(0.59l),type:SAE30orSAE10W-30
detergentoilwithanAPIserviceclassicationofSF,
SG,SH,SJ,SL,orhigher.
1.Movethemowertoalevelsurface.
2.Removethedipstick(Figure4).
Figure4
1.Theoillevelisatits
maximum.
3.Theoillevelistoo
low—addoiltothe
crankcase.
2.Theoillevelistoo
high—removeoilfrom
thecrankcase.
3.Slowlypouroilintotheoilllhole,wait3minutes,
andchecktheoillevelonthedipstickbywipingthe
dipstickcleanandtheninserting,butnotscrewing
in,theoilllcapintothehole(Figure4).
Note:Filltheenginecrankcasewithoiluntilthe
dipstickindicatesthattheengineoilleveliscorrect
asshownin
Figure4.Ifyouoverlltheenginewith
oil,removetheexcessoilasdirectedinChanging
theEngineOil.
4.Installthedipstickandhandtightenitsecurely.
Important: Change the engine oil after the r st
5 operating hour s ;changeityearlythereafter.
RefertoChangingtheEngineOil.
ProductOverview
Figure5
1.Sparkplug5.Grassbag
2.Oilll/Dipstick(notshown)
6.Fueltankcap
3.Recoilstarthandle
7.Cuttingheightlevers(4)
4.Bladecontrolbar
8.Airlter
Figure6
1.Reardischargedeector(optional)
5
