Maintenance
Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
CAUTION
Ifyouleavethekeyintheswitch,someonecouldaccidentlystarttheengineandseriously
injureyouorotherbystanders.
Removethekeyfromtheswitchbeforeyouperformanymaintenance.
RecommendedMaintenanceSchedule(s)
MaintenanceService
Interval
MaintenanceProcedure
Beforeeachuseordaily
•Greasethebearings(immediatelyaftereverywashing).
•Checkthetinesandtinebolts(replaceasrequired).
•Checkthehydrauliclinesforleaks,loosettings,kinkedlines,loosemounting
supports,wear,weather,andchemicaldeterioration.
Beforestorage
•Greasethebearings
GreasingtheTiller
ServiceInterval:Beforeeachuseordaily
(immediatelyaftereverywashing).
Beforestorage
Greaseimmediatelyaftereverywashing.
GreaseType:General-purposegrease
1.Parkthemachineonalevelsurfaceand
disengagetheauxiliaryhydraulics.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.GreasetherotorbearingshowninFigure5.
4.Wipeupanyexcessgrease.
g271903
Figure5
ReplacingtheTillerTines
ServiceInterval:Beforeeachuseordaily—Check
thetinesandtinebolts(replaceas
required).
Note:Wornordulltinesdegradetheperformance
ofthetiller.
1.Parkthemachineonalevelsurfaceand
disengagetheauxiliaryhydraulics.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Notethedirectionthatthetillertineisoriented.
4.Removethebolt(5/8x1-3/4inch),nut(5/8
inch),andtine(Figure6).
g271900
Figure6
1.Bolt(5/8x1-3/4inch)3.Nut(5/8inch)
2.Tine
5.Cleandirtanddebrisfromthetinepocket.
