Toro 29518 - Product Overview; Controls

g020266
Figure8
1.Hairpin
3.Cylinderstop
2.Clevispin4.Cylinder
11.Connectthespark-plugwires.
ProductOverview
g020220
Figure9
1.Platform
4.Enginecontrols
2.Parking-brakeknob5.Fuelcap
3.Motion-controllevers
Controls
Motion-ControlLevers
Themotion-controlleversarelocatedoneachsideof
thetopconsoleandcontroltheforwardandreverse
motionofthemachine.
Movetheleversforwardorbackwardtocontrolthe
drivewheelonthesamesideforwardorreverse
respectively.Thewheelspeedisproportionaltothe
amountyoumovethelever.
Important:Thetinesrotatewhenthe
motion-controlleversaremovedoutoftheneutral
position.
