13
Assembly
Loose Parts
Note: Use the chart below to verify all parts have been shipped.
DESCRIPTION QTY. USE
Castor assemblies
Bolt 3/8–16 x 3/4” (19 mm)
Flange nut 3/8–16
2
8
8
Install front castors to mower
Upper handle
Bolt 3/8–16 x 1” (26 mm)
Locknut 3/8–16
Plastic terminal
Wire tie
1
4
4
1
1
Install upper handle to frame
Install wire harness to handle
Rod fitting
Clevis pin
Washer 1/4”
Hairpin cotter
2
2
2
4
Install traction control rods
PTO rod
Hairpin cotter
1
2
Install PTO rod
Shift lever
Rubber seal
Square hole washer
Spring washer
Locknut
1
1
1
1
1
Install shift lever to transmission
