Note:Discardthe2mountingboltsandat
washers.
2.Removethe2nutsandvinylcaps(ifpreviously
installed)securingtheupperseatbrackettothe
leftsideoftheseatsuspension(Figure7).
3.LooselymounttheR-clampstotheseatbracket
studswiththe2nutspreviouslyremoved(Figure
7).
Note:PositiontheR-clampsunderthe
seat-suspensiontabs.
g001888
Figure7
1.R-clamps4.Manualtube
2.Upperseatbracket5.Vinylcap
3.Seatsuspension
4.InstallthemanualtubeintotheR-clampsand
tightenthenuts(Figure7).
5.Insertthevinylcapsontotheseatbracketstuds.
6
AdjustingtheRollBar
NoPartsRequired
Procedure
1.Removethehairpincotterpinsandremovethe
2pinsfromtherollbar(Figure8).
g001199
Figure8
1.Rollbar3.Hairpincotter
2.Pin
2.Raisetherollbartotheuprightpositionand
installthe2pinsandsecurethemwiththe
hairpincotters(Figure8).
Note:Therollbarisaneffectivesafetydevice.
Keeptherollbarintheraisedandlocked
position.Lowertherollbartemporarilyonly
whenabsolutelynecessary.
Important:Donotweartheseatbeltwhen
therollbarisinthedownposition.
7
ActivatingandCharging
theBattery
NoPartsRequired
AddingElectrolytetotheBattery
WARNING
Batteryelectrolytecontainssulfuricacid,
whichislethalifconsumedandcauses
severeburns.
•Donotdrinkelectrolyteandavoidcontact
withskin,eyes,orclothing.Weareye
protectiontoshieldyoureyesandrubber
glovestoprotectyourhands.
•Fillthebatterywherecleanwaterisalways
availableforushingtheskin.
Important:Useonlyelectrolytewithaspecic
gravityof1.265toinitiallyllbattery.
1.Removethebatteryfromthemachine.
