Greasing the Traction Unit
Before the machine is operated, it must be greased to assure
proper operating characteristics; refer to Lubrication
Maintenance. Failure to grease the machine will result in
premature failure of critical parts.
Note: After setup has been completed, remove protective
edging (used for shipping) from fenders.
Install Rear Weight
To comply with ANSI/OPEI B71.4–1999 Standard, rear weight must be added to rear of traction unit. Use chart below to
determine weight requirements. Order parts from your local Authorized Toro Distributor.
Cutting Unit
Description
Rear Weight
Required
Weight Part
Number
Weight Description Qty.
72″ Side Discharge
(Model No. 30722)
or
72″ Rear Discharge
(Model No. 30710)
or
Guardian 72″
Recycler
(Model No. 30716)
105 lb.
24–5780
&
24–5790
325–8
3253–7
3–8847
3217–9
Rear Weight Kit
(two 35 lb. weights and mounting hardware)
&
Rear Weight Kit
(one 35 lb. weight)
Capscrew 1/2–13 x 2”
Lockwasher 1/2”
Spacer
Nut 1/2”
1
1
2
2
2
2
72” Flex Deck
(Model 30799)
210 lb. 24–5780 Rear Weight Kit
(two 35 lb. weights and mounting hardware)
3
