5.Rotatetheentiretierodassemblythesamedirection
(inwardoroutward)one(1)completerevolution.
Tightenclampatconnectedendoftierod.
6.Installtheballjointintheaxlecasesupportand
tightenthenutngertight.Measuretoe-in.
7.Repeatprocedureifnecessary.
8.Tightenthenutandinstallanewcotterpinwhen
theadjustmentiscorrect.
CoolingSystem
Maintenance
ServicingtheEngineCooling
System
ServiceInterval:Beforeeachuseordaily
Removedebrisfromtheenginearea,oilcoolerand
radiatordaily.Cleanthemmorefrequentlyindirty
conditions.
1.Unlatchandswingopenrearscreen(Figure51).
Cleanthescreenthoroughlyofalldebris.
Note:Toremovescreen,liftoffhingepins.
Figure51
1.Rearscreenlatch
2.Rotatelatches(Figure52)securingtheoilcoolerto
theframe.
Figure52
1.Oilcoolerlatches
3.Pivottheoilcoolerrearward.Cleanbothsidesofthe
oilcoolerandradiatorarea(Figure53)thoroughly
