DrillingtheMountingHolesinthe
RearBumperfortheLicensePlate
UsingthedimensionsshowninFigure5,locateand
drill2holes(9/32inch)throughtheoutsidewallofthe
rearbumper.
g371179
Figure5
1.8.3cm(3-1/3inches)3.52.07cm(20-1/2inches)
2.13.3cm(5-1/4inches)4.Drillahole(9/32inch)
here.
3
InstallingtheHeadlights
Partsneededforthisprocedure:
1Rightheadlightbracket
1
Leftheadlightbracket
6
Bolt(3/8x2-1/2inches)
6
Flangenut(3/8inch)
8
Washer(3/8x7/8inches)
2Rubberhanger
4
Spacer
4
Bolt(5/16x1-5/8inches)
4
Flangenut(5/16inch)
1Rightheadlightassembly
1
Leftheadlightassembly
2Bent-platebracket
InstallingtheHeadlightBracketto
aROPSModel
1.Fastentheleftandrightheadlightbracketsto
thefrontoftheroller-supporttubewith6bolts
(3/8x2-1/2inches)and6angenuts(3/8inch)
asshowninFigure6.
g029788
Figure6
1.Installedheadlightbracket3.Headlightbracket
2.Bolts(3/8x2-1/2inches)4.Flangenuts(3/8inch)
Note:Positiontheboltssothattheangenuts
aretowardthefrontofthetractionunit.
2.Fastentheleftandrightheadlightstothe
headlightbrackets(Figure7)withthefasteners
suppliedwiththelights.
7
