Note:Ensurethattheturn-signallensonthe

headlightispositionedtowardtheoutsideofthe

tractionunit.

g371180

Figure7

Rightheadlightassemblyshown

1.Headlight4.Pivotbracket

2.Pivotboltwithlocknut5.Washer

3.Mountingbolt

6.Locknut(M12)

3.Tightenthelocknuttormlyholdtheheadlight

assemblytotheheadlightbracket.

Note:Donotovertightenthelocknut.

InstallingtheHeadlightBracketto

aCabModel

1.Installabent-platebracketontoeachofthe

uppercornersofthelowerfrontpanelofthecab

withtheexistingscrewsasshowninFigure8.

g034337

Figure8

1.Bolt(5/16x1-5/8inches)

5.Rubberhanger

2.Washer

6.Flangenut(5/16inch)

3.Bent-platebracket

7.Screw(existing)

4.Spacer

2.Looselyinstallarubberhangertoeach

bent-platebracketwithabolt(5/16x1-5/8inch),

2washers(3/8inch),aspacer,andaangenut

(5/16inch)asshowninFigure8.

3.Looselyinstalltheleftandrightheadlight

bracketstothefrontoftheroller-supporttube

with6bolts(3/8x2-1/2inches)andangenuts

(3/8inch).Positionthebracketsasshownin

Figure9.

Note:Ensurethattheholesinthebent-plate

bracketsalignwiththeholesintherubber

hangers.
