Figure14
1.Backrestknob3.Lumbarsupport
adjustmentknob
2.Seatsuspensionknob4.Seatpositionadjustment
lever
2.Slidetheseattothedesiredpositionandreleaselever
tolockinposition.
3.Verifythattheseathaslockedintoplacebyattempting
tomoveitbackandforth.
ChangingtheSeatSuspension
Theseatcanbeadjustedtoprovideasmoothandcomfortable
ride.Positiontheseatwhereyouaremostcomfortable.
Withoutsittingontheseat,turntheknobinfronteither
directiontoprovidethebestcomfort(Figure14).
Figure15
1.Seatsuspensionknob2.Operatorweightsetting
ChangingtheBackPosition
Thebackoftheseatcanbeadjustedtoprovideacomfortable
ride.Positionthebackoftheseatwhereitismost
comfortable.
Toadjustit,turntheknob,undertheright-sidearmrest,in
eitherdirectiontoprovidethebestcomfort(
Figure14).
ChangingtheLumbarSupport
Thebackoftheseatcanbeadjustedtoprovideacustomized
lumbarsupportforyourlowerback.
Toadjustit,turntheknob,undertheleft-sidearmrest,in
eitherdirectiontoprovidethebestcomfort(Figure14).
PositioningtheDeluxeSeat
Figure16
1.Fore/Aftadjustmentlever
4.Armrestadjustmentknob
2.Weightadjustmentlever5.Lumbarsupportadjusting
knob
3.Backrestlockinglever
ChangingtheWeightAdjustment
Theseatcanbeadjustedtoprovideasmoothandcomfortable
ride.
Important:Toadjusttheseatforthedriversweightthe
drivermustbeseatedandtheignitionkeymovedtothe
Onposition.
Theseatisadjustedforthedriver’sweightbypullingor
pressingtheweightadjustmentlever(
Figure16).
Thedriver’sweightisadjustedcorrectlywhenthearrowisin
themiddleclearareaoftheviewingwindow .
Withinthisviewingarea,theseatcanbeadjustedtoa
minimumspringmovement.
Whentheminimum/maximumweightadjustmenthasbeen
reached,youcanhearitreachingtheupperorlowerendstop.
Important:Topreventinjurytotheoperatorand/or
damagetothemachine,thesettingforthedriver’s
weightandtheseatmustbecheckedandadjusted
beforethemachineisoperated.
Note:Toavoidcompressordamageduringweight
adjustment,thecompressormustbeoperatednolongerthan
1minute.
