Toro 33518 - Servicing the Transmission Fluid; Servicing the Auxiliary Hydraulic Fluid

4
ServicingtheTransmission
Fluid
NoPartsRequired
Procedure
Transmissionuidtype:ToroHypr-oil500
Themachineisshippedwithhydraulicuidinthe
expansiontank.
1.Runthemachineforapproximately15minutes
topurgeanyextraairoutofthehydraulic
system.
2.Shutofftheengineandallowthemachineto
cool.
3.Checkthehydraulic-uidlevelintheexpansion
tank(Figure5).
Note:Thetransmission-uidlevelshouldcover
theFullColdlinemoldedintothesideofthe
tank.
g025891
Figure5
1.Cap3.FullColdline
2.Fillerneck(expansion
tank)
4.Ifnecessary,addthespeciedtransmissionuid
untiltheuidlevelisattheFullColdlineofthe
expansiontank(Figure5).
5.Installthecapontotheexpansiontankand
tightenthecapuntilitissnug.
Note:Donotovertightenexpansion-tank
cap.
5
ServicingtheAuxiliary
HydraulicFluid
NoPartsRequired
Procedure
Hydraulicuidtype:AW-32hydrooil
Note:Themachineisshippedwithhydraulicuid
inthereservoir.
1.Runthemachineforapproximately15minutes
topurgeanyextraairoutofthehydraulic
system.
2.Completelyraiseandlowerthetines3timesto
purgetheair.
3.Shutofftheengineandallowthemachineto
cool.
4.Loosenthe4boltsinsidetheframesecuringthe
padtothemachine.
5.Liftthepadupandbacktoremoveit(Figure6).
G018375
g018375
Figure6
6.Removethecapandcheckthehydraulic-uid
levelinthereservoir(Figure7).
Note:Thehydraulic-uidlevelshouldcoverthe
wordColdthatisembossedintothebafeof
thereservoir.
