Toro 33518 - Controls; Motion-Control Levers

decal121-6163
121-6163
1.Presstolowerthetines.2.Releasetoraisethetines.
decal126-2054
126-2054
1.Wheellugnuttorque129N∙m(95ft-lb)(4x)
2.Wheelhubnuttorque319N∙m(235ft-lb)
3.ReadandunderstandtheOperator’sManualbefore
performinganymaintenance;checkthetorqueevery100
hours.
decal121-6164
121-6164
1.Fast6.Wheelsandtinesrotatewhenmoving
backward
11.Warning—keepbystandersasafe
distanceawayfromthemachine.
2.Slow7.Continuous-variablesetting
12.Warning—donotoperatethemachine
unlessyouaretrained.
3.Neutral
8.Choke—on
13.Thrownobjecthazard—pickupdebris
beforeoperatingthemachine.
4.Reverse
9.Choke—off14.Warning—keepawayfrommoving
parts;keepallguardsinplace.
5.Wheelsandtinesrotatewhenmoving
forward
10.Warning—readtheOperator’sManual.15.Warning—shutofftheengine,engage
theparkingbreak,andremovethekey
beforeleavingthemachine.
