4.Tightenthejamnut(Figure37),ensuringthereisslight
tensiononthecable.
5.Ifthetractioncableisproperlyadjustedbutaproblem
remains,contactanAuthorizedServiceDealer.
CheckingandAdjustingthe
Auger/ImpellerCable
ServiceInterval:Aftertherst2hours—Inspectthe
auger/impellercableandadjustitif
necessary.
Yearly—Inspecttheauger/impellercableandadjust
orreplaceitifnecessary.
1.Loosenthejamnut.
2.Engagetheauger/impellerleverandholditinplace
(Figure38).
Figure38
3.Loosenortightentheturnbuckletoadjustthespring
lengthto7cm(2.75inches)asshowninFigure39.
2
1
3
g019047
4
Figure39
1.Jamnut
3.Spring
2.Turnbuckle
4.7cm(2.75inches)
4.Tightenthejamnut(Figure39),ensuringthereisslight
tensiononthecable.
5.Iftheauger/impellercableisproperlyadjustedbut
aproblemremains,contactanAuthorizedService
Dealer.
Checkingthe
Auger-Gearbox-OilLevel
ServiceInterval:Yearly—Checktheauger-gearboxoiland
addoilifnecessary.
1.Movethemachinetoalevelsurface.
2.Cleantheareaaroundthepipeplug(Figure40).
1
G016782
Figure40
1.Pipeplug
3.Removethepipeplugfromthegearbox.
4.Checktheoillevelinthegearbox.Theoilshouldbe
9.5mm(3/8inch)belowthelleropening.
5.Iftheoillevelislow ,addGL-5orGL-6,SAE80-90
EPgearoillubricanttothegearboxuntiltheoillevelis
9.5mm(3/8inch)belowthelleropening.
Note:Donotusesyntheticoil.
6.Installthepipepluginthegearbox.
