Toro 37772 - Installing the Chute; Installing the Chute-Control Rod

3
InstallingtheChute
Partsneededforthisprocedure:
2Nut
2
Carriagebolt
2Flatwasher
Procedure
1.Placethechuteontheframeandthealignthedischarge
chutemounttothechutesupport.
3
1
2
g019379
Figure9
1.Carriagebolt
3.Nut
2.Flatwasher
2.Securethedischargechutemountusing2bolts,2nuts,
and2atwashers.
4
InstallingtheChute-Control
Rod
Partsneededforthisprocedure:
2
Carriagebolt
2Locknut
Procedure
1.UnwraptheQuickStickandrotateitsothatitis
uprightandinthecenter.
2.Holdthebluetriggercapdownandpulltheleverfully
rearward.
Note:Thedischargechuteanddeectorshouldface
forward.Iftheydonot,holdthebluetriggercap
down(butdonotmovetheQuickStick)androtatethe
dischargechuteuntiltheydo.
3.Aligntheattenedbackendofthelongchute-control
rodwiththeattenedfrontendoftheshortrod
thatextendsfromthecontrolpanelsothattheynest
together(Figure10).
Figure10
1.Shortrod
2.Longchute-controlrod
4.Insertthefrontendoftherodintotheopeningin
thebackofthechute-gearcoveruntilitslidesintothe
chutegear(Figure11).
7
