Toro 74020 - Adjusting the Height of Cut

AdjustingtheHeightofCut
ForMachineswithaDeck-Lift
Pedal
UsingtheTransportLock
1.Pushthedeck-liftpedalfullyforwardtolockthe
mowerdeckintheTRANSPORTposition(Figure
29).
2.Pushthedeck-liftpedalforwardandpushthe
transportlockforwardtotheUNLOCKposition,
thenslowlylowerthemowerdeck.(Figure29).
g332768
Figure29
1.LOCKposition—the
mowerdecklocksinto
thetransportposition.
3.Pushonthedeck-liftpedal
usingyourfoottoraisethe
mowerdeck.
2.UNLOCKposition—the
mowerdeckdoesnotlock
intothetransportposition.
AdjustingtheHeight-of-CutPin
Youcanadjusttheheightofcutfrom38to140mm
(1-1/2to5-1/2inches)in6mm(1/4inch)increments
byrelocatingtheclevispinintodifferentholelocations.
1.Pushthedeck-liftpedalfullyforwardtolockthe
mowerdeckintheTRANSPORTposition(alsothe
140mm/5-1/2inchescuttingheightposition)as
showninFigure30.
2.Toadjust,removethepinfromtheheight-of-cut
bracket(Figure30).
3.Selectaholeintheheight-of-cutbracket
correspondingtotheheightofcutdesired,and
insertthepin(Figure30).
4.Pushthedeck-liftpedalforward,pushthe
transportlockforward,andslowlylowerthe
mowerdeck.
g332767
Figure30
1.Deck-liftpedal3.Height-of-cutpin
2.Height-of-cutbracket
4.Transport-locklever
28
