Toro 74020 - Adjusting the Height of Cut; Adjusting the Anti-Scalp Rollers

AdjustingtheHeightofCut
ForMachineswithanElectric
DeckLift
1.Pushuponthedeck-liftswitch(Figure31).
g332765
Figure31
1.Pushuptoraisethedeck.2.Pushdowntolowerthe
deck.
2.Selectaholeintheheight-of-cutbracket
correspondingtotheheightofcutdesired,and
insertthepin(Figure32).
3.Pushdownonthedeck-liftswitchuntilthe
height-of-cutlinkageslightlycontactsthe
height-of-cutpin(Figure32).
Note:T oomuchcontactbetweenthe
height-of-cutlinkageandheight-of-cutpincan
negativelyaffectthemowerdeckheightofcut
andleveling.
g361935
Figure32
1.Height-of-cutpin3.Height-of-cutbracket
2.Height-of-cutlinkage
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,adjustthe
heightoftheanti-scalprollers.
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andengagetheparking
brake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Adjusttheanti-scalprollersasshowninFigure
33,Figure34,andFigure35.
g029955
Figure33
1.Anti-scalproller4.Flangenut
2.Spacer
5.Bolt
3.Bushing
g029956
Figure34
1.Anti-scalproller3.Flangenut
2.Bushing4.Bolt
29
