Decal144-0405isformachinesnotequippedwithan

optionalheadlight.

decal144-0405

144-0405

1.Headlights3.Enginespeed—slow

2.Enginespeed—fast

decal144-2669

144-2669

1.Checktheengine-oillevel.4.Greasethecasterwheel.

2.Checkthehydraulic-uid

level.

5.ReadtheOperator’s

Manualbeforeperforming

maintenance.

3.Checkthetirepressure.

decal144-2687

144-2687

1.Tractionbeltrouting

Decal144-6569isformachinesequippedwitha

headlight.

decal144-6569

144-6569

1.Headlights3.Enginespeed—slow

2.Enginespeed—fast
