Operation
27
Positioning
the Seat
The seat can move forward and backward. Position
the seat where you have the best control of the
machine and are most comfortable.
1. To adjust, move the lever sideways to unlock
seat (Fig. 15).
2. Slide the seat to the desired position and release
lever to lock in position.
1
1200
m–3655
Figure 15
1. Adjustment
knob
Pushing
the Machine by Hand
IMPORTANT: Always push the machine by
hand. Never tow the machine because
hydraulic damage may occur.
To Push the Machine
1. Disengage the power take off (PTO) and turn the
ignition key to “OFF” to stop the engine.
2.
Rotate the by-pass valves counterclockwise 1
turn to push. This allows hydraulic fluid to
by-pass the pump enabling the wheels to turn
(Fig. 16).
IMPORTANT: Never rotate by-pass valve
more than 2 turns so the valve does not come
out of the body causing fluid to run out.
To Operate the Machine
1. Turn the by-pass valves in to operate (Fig. 16).
Note: The machine will not drive unless
by-pass valves are turned in.
1
Figure 16
1. By-pass
valve
