Toro 74282 - Fuel System Maintenance; Replacing the Fuel Filter; Servicing the Fuel Tank

FuelSystem
Maintenance
ReplacingtheFuelFilter
ServiceInterval:Every200hours
Neverinstalladirtylterifitisremovedfromthefuel
line.
1.DisengagethePTO,movethemotioncontrollevers
totheneutrallockedposition,andsettheparking
brake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Allowthemachinetocooldown.
4.Closethefuelshutoffvalve(Figure38).
Figure38
1.Fuellter3.Fuelshutoffvalve
2.Hoseclamp
5.Squeezetheendsofthehoseclampstogetherand
slidethemawayfromthelter(Figure38).
6.Removethelterfromthefuellines.
7.Installanewlterandmovethehoseclampsclose
tothelter(Figure38).
8.Openthefuelshutoffvalve.
ServicingtheFuelTank
Incertainconditions,gasolineisextremely
ammableandhighlyexplosive.Areor
explosionfromgasolinecanburnyouand
othersandcandamageproperty.
•Draingasolinefromthefueltankwhenthe
engineiscold.Dothisoutdoorsinanopen
area.Wipeupanygasolinethatspills.
•Neversmokewhendraininggasoline,and
stayawayfromanopenameorwherea
sparkmayignitethegasolinefumes.
1.Parkthemachineonalevelsurfacetoensurethat
thefueltanksdraincompletely.
2.Disengagethepowertakeoff(PTO),settheparking
brake,stoptheengine,andremovethekey.
3.Closethefuelshutoffvalve(Figure38).
4.Loosenthehoseclampatthefuellterandslideit
upthefuellineawayfromthefuellter(Figure38).
5.Disconnectthefuellinefromthefuellter
(Figure38).
6.Openthefuelshutoffvalve.
Note:Allowgasolinetodrainintoafuelcontainer
canordrainpan(Figure38).
Note:Nowisthebesttimetoinstallanewfuel
lterbecausethefueltankisempty.
7.Installthefuellineontothefuellter.Slidethehose
clampclosetothefuelltertosecurethefuelline
(Figure38).
34
