• Main F1-30 amp , blade-type
• Charg e Circuit F2-25 amp , blade-type
• Optional Headlight Kit-10 amp , blade type
1. Raise the seat to g ain access to the fuse holder
( Figure 35 ).
2. T o re place a fuse , pull out on the fuse to remo v e
it ( Figure 35 ).
Figure 35
1. Main-30 amp
3. For optional Headlight
Kit-10 amp
2. Charge circuit-25 amp
4. Battery
Drive System
Maintenance
Checking the Tire Pressure
Maintain the air pressure in the front and rear tires
as specified. Unev en tire pressure can cause unev en
cut. Chec k the pressure at the v alv e stem after ev er y
50 operating hours or monthly , whic hev er occurs first
( Figure 36 ). Chec k the tires when they are cold to g et
the most accurate pressure reading .
R ear Tires: 13 psi (90 kP a)
F ront Tires (castor wheels): 35 psi (139 kP a)
Figure 36
1. Valve stem
Mower Maintenance
Servicing the Cutting Blades
T he T oro bullhor n log o ( Figure 37 ) is a registered
trademark of the T oro Company . It identifies the
component it appears on as a g en uine T oro par t. T he
log o , de picted belo w , appears on g en uine T oro cutting
blades .
Figure 37
Maintain shar p blades throughout the cutting season
because shar p blades cut cleanly without tearing or
shredding the g rass blades . T earing and shredding
tur ns g rass bro wn at the edg es , whic h slo ws g ro wth
and increases the c hance of disease .
Chec k the cutter blades daily for shar pness , and for
any w ear or damag e . File do wn any nic ks and shar pen
the blades as necessar y . If a blade is damag ed or w or n,
re place it immediately with a g en uine T oro re placement
blade . F or con v enient shar pening and re placement,
y ou ma y w ant to k ee p extra blades on hand.
A w or n or dama ged blade can br eak, and a piece
of the blade could be thr o wn into the operator’ s
or bystander’ s ar ea, r esulting in serious per sonal
injur y or death.
• Inspect the blade periodicall y f or w ear or
dama ge.
• R eplace a w or n or dama ged blade.
29
