Driving Backward
1. Mo v e the lev ers to the center , un-loc k ed
position.
2. T o g o bac kw ard, slo wly pull the motion control
lev ers rearw ard ( Figure 18 ).
T o g o straight, apply equal pressure to both
motion control lev ers ( Figure 18 ).
T o tur n, release pressure on the motion control
lev er to w ard the direction y ou w ant to tur n
( Figure 18 ).
T o stop , push the motion control lev ers to the
neutral position.
Stopping the Machine
T o stop the mac hine , mo v e the traction control
lev ers to neutral and mo v e to loc k ed position,
diseng ag e the po w er tak e off (PTO), and tur n the
ignition k ey to off .
Set the parking brak e when y ou lea v e the mac hine;
refer to Setting the P arking Brak e in Operation ,
pag e 14 . R emember to remo v e the k ey from the
ignition switc h.
Childr en or bystander s may be injur ed if
they mo v e or attempt to operate the tractor
while it is unattended.
Al w ays r emo v e the ignition k ey and set the
par king brak e when lea ving the machine
unattended, ev en if just f or a few min utes.
Adjusting the Height-of-Cut
T he height-of-cut is adjusted from 1-1/2 to
4-1/2 inc h (38 to 114 mm) in 1/4 inc h (6 mm)
increments b y relocating the clevis pin into
different hole locations .
1. Raise the height-of-cut lev er to the transpor t
position (also the 4-1/2 inc h (114 mm) cutting
height position) ( Figure 19 ).
2. T o adjust, remo v e the clevis pin from the
height-of-cut brac k et ( Figure 19 ).
3. Select a hole in the height-of-cut brac k et
cor responding to the height-of-cut desired
and, inser t the clevis pin ( Figure 19 ).
4. Mo v e the lev er to the selected height.
Figure 19
1. Height of cut lever 2. Clevis Pin
Adjusting the Anti-Scalp
Rollers
W henev er y ou c hang e the height-of-cut, it is
recommended to adjust the height of the anti-scalp
rollers .
1. Diseng ag e the PTO , mo v e the motion control
lev ers to the neutral loc k ed position and set
the parking brak e .
2. Stop the engine , remo v e the k ey , and w ait for
all mo ving par ts to stop before lea ving the
operating position.
3. After adjusting the height-of-cut, adjust the
rollers b y remo ving the flang e n ut, bushing,
spacer , and bolt ( Figure 20 , Figure 21 and
Figure 50 ).
Note: T he tw o middle rollers will not ha v e a
spacer ( Figure 21 ).
4. Select a hole so the anti-scalp roller is
positioned to the nearest cor responding
height-of-cut desired.
5. Install the flang e n ut bushing, spacer , and bolt.
T or que to 40-45 ft-lb (54-61 N•m) ( Figure 20 ,
Figure 21 and Figure 50 ).
6. R e peat this adjustment on the other anti-scalp
rollers .
21
