Toro 74441 - Drive System Maintenance; Adjusting the Tracking; Checking the Tire Pressure

Figure42
1.Main,30amp4.Ignitionswitch
2.Chargecircuit,25amp
5.Throttlelever
3.Foroptionalheadlightkit,
10amp
DriveSystem
Maintenance
AdjustingtheTracking
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
Themachinehasaknobforadjustingthetracking
locatedundertheseat.
Important:Adjustthehandleneutralandhydraulic
pumpneutralbeforeadjustingthetracking.Refer
toAdjustingtheHandleNeutralinControlsSystem
Maintenance,page39andAdjustingtheHydraulic
PumpNeutralinHydraulicSystemMaintenance,
page40.
1.Pushbothcontrolleversforwardthesamedistance.
2.Checkifthemachinepullstooneside.Ifitdoes,
stopthemachineandsettheparkingbrake.
3.Unlatchtheseatandtilttheseatforwardtoaccess
thetrackingknob.
4.Tomakethemachinegoright,turntheknobtowards
therightsideofthemachine.RefertoFigure43.
5.Tomakethemachinegoleft,turntheknobtowards
theleftsideofthemachine.RefertoFigure43.
6.Repeatadjustmentuntilthetrackingiscorrect.
Figure43
1.Pumprod3.Trackingknob
2.Turnthiswaytotrackleft
4.Turnthiswaytotrackright
CheckingtheTirePressure
ServiceInterval:Every50hours
