Toro 74621 - Mower Belt Maintenance (continued); Installing the Mower Deck; Replacing the Grass Deflector

removetensionontheidlerpulleyandrollthebelt
offofthepulleys(Figure56).
WARNING
Thespringisundertensionwheninstalledand
cancausepersonalinjury.
Becarefulwhenremovingthebelt.
G015129
1
2
3
4
5
4
6
Figure56
1.Idlerpulley
4.Spring
2.Mowerbelt5.Enginepulley
3.Outsidepulley6.Springremovaltoo
5.Routethenewbeltaroundtheenginepulleyand
mowerpulleys(Figure56).
6.Usingaspringremovaltool,(Toropartno.92-5771),
installtheidlerspringoverthedeckhookand
placingtensionontheidlerpulleyandmowerbelt
(Figure56).
InstallingtheMower
1.Parkthemachineonalevelsurfaceanddisengage
thebladecontrolswitch.
2.Movethemotioncontrolleversoutwardtothe
parkposition,stoptheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Slidethemowerunderthemachine.
4.Lowertheheight-of-cutlevertothelowestposition.
5.Lifttherearofthemowerdeckandguidethehanger
bracketsovertherearliftrod(
Figure55).
6.Attachthefrontsupportrodtothemowerdeckwith
theclevispinandhairpincotter(
Figure54).
7.Installthemowerbeltontotheenginepulley;refer
toReplacingtheMowerBelt.
ReplacingtheGrassDeector
ServiceInterval:Beforeeachuseordaily—Inspectthe
grassdeectorfordamage
WARNING
Anuncovereddischargeopeningcouldallowthe
lawnmowertothrowobjectsintheoperator'sor
bystander'sdirectionandresultinseriousinjury.
Also,contactwiththebladecouldoccur.
Neveroperatethemachinewithoutgrassdeector,
dischargecoverorgrasscollectionsysteminplace.
1.LocateitemsshowninFigure57.
G014636
1
2
3
4
5
6
7
Figure57
1.Mowerdeck
5.Spring
2.Grassdeector6.Nut(3/8inch)
3.Grassdeectorbracket7.Shortstand-off
4.Rod
2.Removethenut(3/8inch)fromtherodunderthe
mower(Figure57).
3.Slidetherodoutoftheshortstand-off,spring,and
grassdeector(Figure57).Removethedamaged
orworngrassdeector.
4.Replacethegrassdeector(Figure57).
5.Sliderod,straightend,throughthereargrass
deectorbracket.
