DrivingBackward
1.Movetheleverstothecenter,unlockedposition.
2.Togobackward,lookbehindyouanddown,asyou
slowlypullthemotion-controlleversrearward(Figure
20).
G008953
Figure20
Togostraight,applyequalpressuretoboth
motion-controllevers(Figure20).
Toturn,releasethepressureonthemotion-control
levertowardthedirectionyouwanttoturn.
Tostop,pushthemotion-controlleverstoneutral.
StoppingtheMachine
Tostopthemachine,movethemotion-controlleversto
neutralandoutwardtotheparkposition,disengagethe
blade-controlswitch,ensurethethrottleisintheFast
position,andturntheignitionkeytooff.
Note:Remembertoremovethekeyfromtheignitionswitch.
WARNING
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethemowerwhileitis
unattended.
Alwaysremovetheignitionkeyandmovethe
motion-controlleversoutwardtotheparkposition
whenleavingthemachineunattended,evenifjust
forafewminutes.
AdjustingtheHeight-of-Cut
Height-of-cutiscontrolledbytheleverlocatedtotherightof
theoperatingposition(Figure21).
G014476
1
2
3
Figure21
1.Height-of-cutlever3.115mm(4.5
inches)—transport
position
2.Height-of-cutpositions
1.Pullupandinwardonthelevertomoveittothe
desiredcuttingposition.
2.Onceatthedesiredcuttingposition,slowlylowerthe
leveruntilitengagestheposition.
Note:Thetransportpositionisthehighestheight-of-cut
positionorcuttingheight(115mm(4.5inches))asshown
inFigure21.
PositioningtheSeat
1.Raisetheseatandloosentheadjustmentboltsjust
enough,sothattheseatcanmove(Figure22).
G014477
1
Figure22
1.Adjustmentbolt
2.Movetheseattothedesiredposition,andtightenthe
bolts.
19
