Toro 74683 - Removing the Discharge Cover for Side-Discharging; Installing the Discharge Cover for Mulching

RemovingtheDischarge
CoverforSide-Discharging
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch(PTO),andmovethe
motion-controlleversoutwardtothePARK
position.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Releasetheexiblelatchfromthelatchretainer
onthedischargecoverandpivotthedischarge
covertotheright(Figure11).
g293897
Figure11
1.Latchretainer3.Dischargecover
2.Latch
4.Releasethehook-shapedlatchontopofthe
dischargecoverfromthepivotrod(Figure15).
5.Anglethemetaltabonthedischargecoverout
oftheslotinthebracketweldedtothemower
deck(Figure12).
g230250
Figure12
1.Dischargecover3.Bracketonthemower
deck
2.Metaltab
InstallingtheDischarge
CoverforMulching
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch(PTO),andmovethe
motion-controlleversoutwardtothePARK
position.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Anglethemetaltabonthedischargecoverinto
theslotinthebracketweldedtothemowerdeck
(Figure13).
g230248
Figure13
1.Dischargecover3.Bracketonthemower
deck
2.Metaltab
4.Pivotthedischargecoverbackandtowardthe
decksothatthedischargecoveralignswiththe
mowerdeck(Figure14).
g230249
Figure14
5.Onthetopofthedischargecover,engagethe
hook-shapedlatcharoundthepivotrodofthe
deectorassembly(Figure15).
15
