Pre-Maintenance

Procedures

ReleasingtheMower-Deck

Curtain

Loosenthe2bottomboltsofthecurtaintoaccessthe

topofthemowerdeck(Figure34).

g295619

Figure34

1.Bottombolt

2.Curtain

Note:Alwaystightentheboltstoconnectthecurtain

aftermaintenance.

RaisingtheMachine

Usejackstandstosupportthemachinewhenyou

raiseit.

WARNING

Supportingthemachineonthelowermufer

shield(Figure35)maydamagetheshieldand

causethemachinetofall,injuringyouor

bystanders.

Donotusethelowermufershieldtoliftor

supportthemachine.

g299647

Figure35

1.Lowermufershield
