Toro 74687 - Removing the Mower Deck

g294195
Figure70
8.Installthewasherandhairpincotter(Figure70).
9.Repeatsteps6through8fortheothersideof
themachine.
10.Checktheside-to-sidelevelagain;repeatthis
procedureuntilthemeasurementsarecorrect.
11.Continuelevelingthemowerdeckbychecking
thefront-to-rearbladeslope;refertoAdjusting
theFront-to-RearBladeSlope(page46).
AdjustingtheFront-to-RearBlade
Slope
1.Rotatetheadjustmentnutinthefrontofthe
mower(Figure71).
g294471
Figure71
1.Adjustingrod3.Adjustmentnut
2.Adjustingblock
2.T oraisethefrontofthemowerdeck,tightenthe
adjustmentnut.
3.T olowerthefrontofthemowerdeck,loosenthe
adjustmentnut.
4.Afteradjustment,checkthefront-to-rearslope
again,continueadjustingthenutuntilthefront
bladetipis1.6to7.9mm(1/16to5/16inch)
lowerthantherearbladetip;refertoChecking
theFront-to-RearBladeSlope(page44).
5.Whenthefront-to-rearbladeslopeiscorrect,
checktheside-to-sidelevelofthemowerdeck
again;refertoCheckingtheSide-to-SideLevel
(page44).
RemovingtheMowerDeck
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch(PTO),andmovethe
motion-controlleversoutwardtothePARK
position.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Lowertheheight-of-cutlevertothelowest
position.
4.Loosenthebottom2boltsholdingthe
mower-deckcurtaintothemowerdeck.Referto
ReleasingtheMower-DeckCurtain(page29).
5.Removethehairpincotterfromthefrontsupport
rod,andremovetherodfromthedeckbracket
(Figure72).
g366001
Figure72
1.Frontsupportrod2.Deckbracket
6.Carefullylowerthefrontofthemowerdeckto
theground.
7.On1sideofthemachine,removethewasher
andhairpincotterfromthedeckpin(Figure73).
46
