Toro 74687 - Installing the Mower Deck; Replacing the Grass Deflector

g295768
Figure73
1.Liftarm
3.Washer
2.Hairpincotter
8.Removetheliftarmfromthedeckpin(Figure
73).
9.Repeatsteps7and8fortheothersideofthe
machine.
10.Slidethemowerdeckrearwardtoremovethe
mowerbeltfromtheenginepulley.
11.Slidethemowerdeckoutfromunderneaththe
machine.
Note:Retainallpartsforfutureinstallation.
InstallingtheMowerDeck
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch(PTO),andmovethe
motion-controlleversoutwardtothePARK
position.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Slidethemowerunderthemachine.
4.Lowertheheight-of-cutlevertothelowest
position.
5.On1sideofthemachine,lifttherearofthe
mowerdeckandinstalltheliftarmtothedeck
pin(Figure73).
6.Installtheliftarmusingthewasherandhairpin
cotter(Figure73).
7.Repeatsteps5and6fortheothersideofthe
machine.
8.Attachthefrontsupportrodtothemowerdeck
withtheclevispinandhairpincotter(Figure72).
9.Installthemowerbeltontotheenginepulley;
refertoReplacingtheMowerBelt(page40).
10.Tightenthebottom2boltsforthemower-deck
curtaintothemowerdeck;refertoReleasing
theMower-DeckCurtain(page29).
ReplacingtheGrass
Deector
ServiceInterval:Beforeeachuseordaily—Inspect
thegrassdeectorfordamage.
WARNING
Anuncovereddischargeopeningcouldallow
themachinetothrowobjectstowardyouor
bystanders,resultinginseriousinjury.Also,
contactwiththebladecouldoccur.
Neveroperatethemachinewithoutthe
grassdeector,thedischargecover,orthe
grass-collectionsysteminplace.
1.Removethenut(3/8inch)fromtherodunder
themower(Figure74).
g298422
Figure74
1.Mowerdeck5.Rod
2.Bafe6.Spring
3.Grassdeector7.Nut(3/8inch)
4.Grass-deectorpivot8.Shortstandoff
2.Slidetherodoutoftheshortstand-off,spring,
bafe,andgrassdeector(Figure74).
47
