Toro 77281 - Product Overview; Controls

ProductOverview
g412513
Figure5
1.Height-of-cutpositions
6.Fuelcap
2.Controls
7.Parking-brakelever
3.Motion-controllevers8.Mowerdeck
4.Rollbar
9.Casterwheel
5.Shockassembly
(machineswithMyRide
only)
10.Anti-scalproller
Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
ControlPanel
g412512
Figure6
1.Chokecontrol(for
carburetedmodelsonly)
5.Lightswitch(formodels
withlightsonly)—optional
kitforothermodels
2.Keyswitch6.Hourmeter
3.Blade-controlswitch
(powertakeoff)
7.USBpowerpoint
4.Throttlecontrol
KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART.Referto
StartingtheEngine(page25).
USBPowerPoint
Usethepowerpoint(Figure6)topowermobile
devices.
