Maintenance
16
Cutting
Blade
To assure a superior quality of cut, keep the blade(s)
sharp. For convenient sharpening and replacement,
you may want to have an extra blade(s).
POTENTIAL HAZARD
• A blade that is worn or damaged could
break apart and pieces could be thrown at
bystanders or at you as you use the mower.
WHAT CAN HAPPEN
• Pieces of blade that may be thrown could
seriously injure or kill you or bystanders.
HOW TO AV
OID THE HAZARD
• Periodically inspect the blade for wear and
damage. Immediately install a new blade if
it is worn or damaged.
Inspecting the Blade(s)
1. Remove the mower; refer to Removing the
Mower, page 9.
2. Inspect the cutting edges (Fig. 23). If the edges
are not sharp or have nicks, remove the blade(s)
and sharpen them; refer to Sharpening the
Blade(s), page 17.
3. Inspect the blade(s), especially the curved area
(Fig. 23). If you notice any damage, wear, or a
slot forming in this area (Fig. 23), immediately
install a new blade.
151
1
2
3
Figure 23
1.
Cutting
edge
2.
Curved area
3.
W
ear/slot forming
Removing the Blade
1. Remove the mower; refer to Removing the
Mower, page 9.
2. Carefully tip the mower over.
3. Remove the nut, flat washer, blade and washer
(Fig. 24). A block of wood may be wedged
between the blade and the mower to lock the
blade when you are removing the bolt.
4. Inspect all parts. If a defect or damage is noticed,
install new parts.
1
2
3
4
5
Figure 24
1.
Nut
2.
Flat
washer – thin
3.
Blade
4.
W
asher – thich
5.
Spindle
