2
All Rights Reserved
Printed in the USA
î 2001 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
Contents
Page
Introduction 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Slope Chart 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety and Instruction Decals 5. . . . . . . . . . . . . . . .
Setup 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loose Parts 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing the Tiller Hitch and Pulleys 7. . . . . . . . .
Installing the Rear Shield 7. . . . . . . . . . . . . . . . . . .
Installing the Lift Cable and Lift Lever 7. . . . . . . .
Removing the Drawbar 9. . . . . . . . . . . . . . . . . . . .
Assembling the Mounting Plate 9. . . . . . . . . . . . . .
Installing the Mounting Plate 9. . . . . . . . . . . . . . . .
Installing the Idler Arm Pulley Assembly 10. . . . . .
Installing the Tiller to the Tractor 10. . . . . . . . . . . . .
Operation 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating the Power Take Off (PTO) 11. . . . . . . . . .
Operating the Attachment Lift Lever 12. . . . . . . . . .
Operating the Attachment Power Lift 12. . . . . . . . .
Adjusting Dial-A-Height 13. . . . . . . . . . . . . . . . . . .
Adjusting Lift Chain 13. . . . . . . . . . . . . . . . . . . . . . .
Removing the Tiller 13. . . . . . . . . . . . . . . . . . . . . . .
Tips for Tilling 14. . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Maintenance Schedule 15. . . . . . . . .
Service Interval Chart 15. . . . . . . . . . . . . . . . . . . . . .
Greasing and Lubrication 16. . . . . . . . . . . . . . . . . . .
Adjusting Drive Belt Tension 16. . . . . . . . . . . . . . . .
Replacing the Power Take Off (PTO) Belt 16. . . . . .
Storage 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction
Read this manual carefully to learn how to operate and
maintain your product properly. The information in this
manual can help you and others avoid injury and product
damage. Although Toro designs and produces safe
products, you are responsible for operating the product
properly and safely.
Whenever you need service, genuine Toro parts, or
additional information, contact an Authorized Service
Dealer or Toro Customer Service and have the model and
serial numbers of your product ready. Figure 1 illustrates
the location of the model and serial numbers on the
product.
1
2276
Figure 1
1. Location of the model and serial numbers
Write the product model and serial numbers in the space
below:
Model No.
Serial No.
This manual identifies potential hazards and has special
safety messages that help you and others avoid personal
injury and even death. Danger, Warning, and Caution are
signal words used to identify the level of hazard. However,
regardless of the hazard, be extremely careful.
Danger signals an extreme hazard that will cause serious
injury or death if you do not follow the recommended
precautions.
Warning signals a hazard that may cause serious injury or
death if you do not follow the recommended precautions.
Caution signals a hazard that may cause minor or moderate
injury if you do not follow the recommended precautions.
This manual uses two other words to highlight information.
Important calls attention to special mechanical
information and Note: emphasizes general information
worthy of special attention.
