Toro 79370 - Page 6

6
DESCRIPTION USEQTY.
Tube—Hydro drive
Tube—Gear drive
Clamp
Cable
Clevis—Long
Clevis—Short
Clevis pin
Cotter pin, 1 inch
Trunnion
Washer, 3/8 inch
Lift lever
Bushing
Shim washer
E-ring
1
1
1
1
1
1
1
2
1
1
1
2
4
2
Installing the lift cable and lift lever
Latching plate
Latch lever
Carriage bolt, 3/8 x 1 inch
Washer, 3/8 inch
Lock nut, 3/8 inch
1
2
2
2
2
Assembling the mounting plate
Latch plate assembly
Link bracket-right
Link bracket-left
Angle spacer (if required)
Carriage bolt 3/8 x 3-1/2 inch
Lock nut, 3/8 inch
1
1
1
1
4
4
Installing the mounting plate
Idler arm assembly
Idler bracket
1
1
Install idler arm pulley assembly
Spring—large
Eye bolt
Lock nut, 3/8 inch
Clevis pin
Cotter pin, 3/4 inch
Belt
Bolt 3/8 x 1-1/4 inch
Lock nut, 3/8 inch
Spring—small
Belt guard
Bolt-self tapping, 1/4 x 1/2 inch
1
1
1
2
2
1
1
2
1
1
2
Installing the tiller to the tractor
