11.Insertacabletiethrougheachofthe2holesinthe
beaconbracket(Figure7),andsecurethecable.
Figure7
1.Holes
12.Onthemaincontrolpanelattherearofthecontrol
pad,removeanddiscardtheblankingplug.
13.Pullouttheswitchconnectorcontaining
orange-red/orangeandblackwiresandpluginthe
switch.
14.Presstheswitchintothecutoutuntilitclicksintoplace
(Figure8).
Figure8
1.Switch
CompletingtheInstallation
1.Installthebulkhead.
2.Applytheseriallabeladjacenttothemachineserial
label.
3.Installthepositive(red)batterycabletothepositive
(+)batteryterminal.
4.Installthenegative(black)groundcabletothenegative
(-)batteryterminal.
5.Lowerandlatchtheenginecover.
Operation
UsingtheBeacon
Toturnonthebeacon,pressthebottomoftheswitch.
Toshutoffthebeacon,pressthetopoftheswitch.
Note:Theignitionswitchmustbeinposition1forthe
beacontowork.
Maintenance
ReplacingtheFuse
Thebeaconfuseislocatedinthemainfuseboxofthe
machine.Itisa10Afuselocatedinthethirdpositionfrom
theright(Figure9).
Toreplacethefuse,removeitbysimplypullingitoutfrom
thefuseblock,andinstallanewfuse.
Important:Alwaysuseafuseofthesametypeand
amperageastheoneyouarereplacing;otherwise,you
coulddamagetheelectricalsystem.
Figure9
1.Fuseblock3.Fuse
2.Cover
