Toro DH 140 Setup Instructions

1
InstallingtheSteering
Wheel
Partsneededforthisprocedure:
1
Steeringwheel
1Rollpin
1
Spacer
Procedure
1.Positionthefrontwheelsstraightahead.
2.Installtheplasticspaceroverthesteering-wheel
shaft(smallerdiameterrst).
3.Slidethesteeringwheelovertheshaft,aligning
theholesoneachsideofthesteeringwheel
withtheholesinthespacerandwiththeholes
intheshaft.
4.Drivetherollpinthroughtheholesinthe
steeringwheel,theplasticspacer,andtheshaft
withahammertosecurethesteeringwheel.
2
InstallingtheSeat
Partsneededforthisprocedure:
1
Seat
2Bolts
2Adjustingknob
4Flatwashers
2
Springwashers
Procedure
1.Removetheplasticcoverfromtheseatand
discardit.
2.Settheseatinplaceandsecureitwiththe2
bolts,springwashers,andatwashers(Figure
1).
g012505
Figure1
1.Safetyswitch
3.Adjustingknobsand
washers
2.Boltsandwashers
3.Installthe2adjustingknobsandwashers
(Figure1).
4.Ensurethatthesafetyswitchisconnectedto
theseat(Figure1).
3
AssemblingtheGrass
Collector
Partsneededforthisprocedure:
1
Grasscollector
1
Grasscollectorbottomanddumpframeassembly
2Hingepin
2Pushnut
2
Snapring
Procedure
1.Installapushnutontotheendofeachhingepin
andslideittowithinan1/8inch(3mm)fromthe
endofeachpin(Figure2).
2
