Toro DH 140 Setup Instructions

g012491
Figure2
1.Lockingpin4.Pushnut
2.Holeinthedumpframe5.Snapring
3.Hingepin
2.Slidethecollectorintothedumpframesothat
theholesinthedumpframelineupwiththe
holesinthesidesofthecollector(Figure2).
3.Pushahingepinthroughtheholesoneachside
frominsidethecollector,andsecureeachonthe
outsideusingasnapringinstalledintothegrove
onthepin(Figure2).
4.Turnthelockingpindowntolockthedump
frameinplace(Figure2).RefertotheOperator's
Manualformoreinformation.
5.Liftthecollectorandslideitontothehooks
onthebackofthetractionunit.Refertothe
Operator'sManualformoreinformation.
4
CheckingtheOilLevel
NoPartsRequired
Procedure
Themachinecomesfromthefactorywithoilinthe
enginecrankcase;however,itmaybenecessaryto
addoil.RefertotheOperator’sManualforoiltype,
viscosity,andcrankcasecapacity.Addonlyenough
oiltoraisetheleveltotheFULLmarkonthedipstick.
5
ActivatingtheBattery
NoPartsRequired
Procedure
1.Removethebatteryfromthemachine;referto
theOperator’sManual.
2.Removethellercapsfromthetopofthebattery.
DANGER
Batteryelectrolytecontainssulfuric
acid,whichisfatalifconsumedandcan
severelyburnyou.
•Donotdrinkelectrolyte.
•Avoidcontactwithskin,eyes,or
clothing.
•Wearsafetyglassestoshieldyour
eyesandrubberglovestoprotect
yourhands.
•Fillthebatterywherecleanwateris
availableforushingtheskin.
•Followallinstructionsandcomply
withallsafetymessagesonthe
electrolytecontainer.
3.Slowlypourelectrolyteintoeachcelluntilthe
levelisuptothelowerpartofthetube.
4.Leavethellercapsoff,andconnecta3to4A
batterychargertothebatteryposts.
5.Chargethebatteryatarateof2Aorlessforat
least24hours(12volts).
Important:Useonlyabatterychargersetto
12voltstochargethebattery.
Important:Donotstarttheenginewith
abatterybooster(jumpstarter)pack.
Jump-startingtheenginewithabattery
boosterpackmaydamageelectronic
componentsofthemachine.
WARNING
Chargingthebatteryproducesgasses
thatcanexplode.
Neversmokenearthebattery,andkeep
sparksandamesawayfromthebattery.
3

Toro DH 140 Specifications

General

Brand	Toro
Model	DH 140
Category	Lawn Mower
Language	English
