Traction Control
T o mo v e forw ard, mo v e the traction control
forw ard. T o mo v e rearw ard, mo v e the traction
control rearw ard ( Figure 5 ).
T o tur n, rotate the traction control in the desired
direction ( Figure 5 ).
T he far ther y ou mo v e the traction control in any
direction, the faster the traction unit will mo v e in
that direction.
T o stop , release the traction control.
Figure 5
Loader Arm/Attachment Tilt Lever
T o tilt the attac hment forw ard, slo wly mo v e the
lev er to the right ( Figure 6 ).
T o tilt the attac hment rearw ard, slo wly mo v e the
lev er to the left ( Figure 6 ).
T o lo w er the loader ar ms , slo wly mo v e the lev er
forw ard ( Figure 6 ).
T o raise the loader ar ms , slo wly mo v e the lev er
rearw ard ( Figure 6 ).
Y ou can also push the lev er fully forw ard into a
detent position ( Figure 6 ) to release the loader
ar ms so that the attac hment rests on the g round.
T his allo ws attac hments suc h as the lev eler and
the h y draulic blade to follo w the contours of the
g round (i.e ., float) when g rading .
Figure 6
1. Lower the loader arms 4. Tilt the attachment forward
2. Raise the loader arms
5. Detent (Float) position
3. Tilt the attachment
rearward
By mo ving the lev er to an inter mediate position
(suc h as , forw ard and left), y ou can mo v e the
loader ar ms and tilt the attac hment at the same
time .
Auxiliary Hydraulics Lever
T o operate a h y draulic attac hment in the forw ard
direction, rotate the auxiliar y h y draulics lev er
rearw ard and pull it do wn to the reference bar
( Figure 7 , n umber 1).
T o operate a h y draulic attac hment in rev erse
direction, rotate the h y draulics lev er rearw ard, then
mo v e it left into the upper slot ( Figure 7 , n umber
2).
If y ou release the lev er while in the forw ard
position, the lev er will automatically retur n to the
neutral position ( Figure 7 , n umber 3). If it is in
the rev erse position, it will remain there until y ou
pull it out of the slot.
Figure 7
1. Forward ow hydraulics 3. Neutral
2. Reverse ow hydraulics
