Toro Flex-Force Power System 51834 - Unfolding the Handle

1
UnfoldingtheHandle
Partsneededforthisprocedure:
1Allenwrench
Procedure
1.Unfoldthehandle(AofFigure1).
2.Alignthelockingbuttononthelowershaftwiththeslottedholeontheuppershaftandslidethe2shafts
together(BandCofFigure1).
Note:Thelockingbuttonclicksintotheslottedholewhentheshaftsaresecured(DofFigure1).
3.UsingtheprovidedAllenwrench,tightenthescrewontheshaftconnectoruntilitissecure(EofFigure1).
g333608
Figure1
