Toro Flex-Force Power System 51835T - Page 7

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Allenwrench1
Unfoldtheshaft.
2
Auxiliaryhandleassembly1Installtheauxiliaryhandle.
3
Guard
1Installtheguard.
4
Stringtrimmerstrap
1Installthestrap.
1
UnfoldingtheShaft
Partsneededforthisprocedure:
1Allenwrench
Procedure
1.Unfoldtheshaft(AofFigure3).
2.Alignthelockingbuttononthelowershaftwiththeslottedholeontheuppershaftandslidethe2shafts
together(BandCofFigure3).
Note:Thelockingbuttonclicksintotheslottedholewhenbothshaftsaresecured(DofFigure3).
3.UsingtheprovidedAllenwrench,tightenthescrewontheshaftconnectoruntilitissecure(EofFigure3).
